  • Elektrogas Filtering FG

    FG

    Gas filters

    Filters for gas pipelines with very high holding capacity of dust and impurities, suitable for protection of devices installed downstream. The filter cartridge is a steel supported frame covered with a high performance nonwoven made of polypropylene fibres, which satisfy the stringent requirements of Fire Class F1 according to DIN 53438 and thus are self-extinguishing.

    Inlet and outlet pressure chambers can be provided with gauges, to connect a gas differential pressure switch to monitor the pressure difference.
    When the dust storage capacity is exceeded, the filter element must be replaced.
    FGS1-2 models are provided with a washable mesh filter cartridge.

    Material/Connections
    AlSi
    Rp1/2 … Rp2
    AlSi
    DN65 … DN300
    Operating pressure
    0 … 2 bar
    0 ... 6 bar
    Gas type
    Air and non-aggressive gases (Family 1-2-3, EN 437)
    Special version for Biogas/COG
    Approvals

    Tested and certified according to 97/23/EC
